Overview

SWWheel is a composite graphic class that renders an animated wagon-wheel on a p5.js canvas. It is built entirely from existing SketchWaveJS components — no raw p5 drawing calls appear in SWWheel itself. The class supports continuous rotation, sinusoidal radius oscillation (“breathing”), and full independent color control for its three visual parts.

SWWheel ├── hub → SWDisk (filled center disk — drawn on top) ├── rim → SWDisk (outlined ring at outer radius, stroke only) └── spokes → SWLine[] (n evenly-spaced lines, center → rim edge) Draw order: rim → spokes → hub

Coordinate system: The center point and all radii are in user/grid units. Stroke weights (rimThickness, spokeThickness) are always in screen pixels. Use drawOnGrid(grid) for the normal canvas workflow; use draw() only when working directly in raw pixel coordinates.

Dependencies

All five must be loaded in your HTML before swWheel.js:

Class / Library	File	Role in SWWheel
`p5.js`	CDN	Canvas, rendering engine — `strokeWeight()`, `line()`, etc.
`SWColor`	`shapeClasses/swColor.js`	HSB color objects for hub fill, rim stroke, and spoke stroke
`SWPoint`	`shapeClasses/swPoint.js`	Center point and computed spoke endpoints
`SWLine`	`shapeClasses/swLine.js`	Each individual spoke
`SWDisk`	`shapeClasses/swDisk.js`	Hub (filled) and rim (outlined)
`SWGrid`	`shapeClasses/swGrid.js`	Required only for `drawOnGrid()`

Constructor

const wheel = new SWWheel({ /* options object — all optional */ });

All options are passed as a single destructured object. Every key has a sensible default, so new SWWheel() with no arguments is valid and produces an 8-spoke wheel centered at the grid origin.

Option	Type	Default	Description
`center`	SWPoint	SWPoint(0, 0)	Wheel center in user/grid coordinates
`outerRadius`	number	80	Rim radius in user units. Also seeds `originalOuterRadius`.
`hubRadius`	number	10	Hub disk radius in user units
`numSpokes`	number	8	Number of evenly-distributed spokes
`rimThickness`	number	3	Rim stroke weight in pixels. 0 = invisible rim.
`spokeThickness`	number	2	Spoke stroke weight in pixels
`hubFillColor`	SWColor	undefined	Hub fill. `undefined` lets p5 use its current fill state.
`rimColor`	SWColor	undefined	Rim stroke and hub border color (shared)
`spokeColor`	SWColor	undefined	Spoke stroke color. Each spoke receives its own defensive copy.

Defensive copying: All three color options (and their corresponding setters) apply copy-on-intake. Mutating a SWColor object after passing it to the constructor will not silently change the wheel’s appearance. See the chatlog Turn 10 for a full explanation of the aliasing footgun this prevents.

Public Properties

All constructor options become readable instance properties. For most of them, prefer the setter methods over direct assignment — setters keep the internal SWDisk and SWLine components synchronized.

Property	Type	Notes
`center`	SWPoint	Wheel center (user/grid coordinates)
`outerRadius`	number	Nominal rim radius; updated by `setOuterRadius()`
`originalOuterRadius`	number	Baseline radius; `reset()` restores `currentRadius` to this value
`hubRadius`	number	Hub disk radius (user units)
`numSpokes`	number	Current spoke count
`rimThickness`	number	Rim stroke weight in pixels (0 = hidden)
`spokeThickness`	number	Spoke stroke weight in pixels
`hubFillColor`	SWColor	Owned copy of the hub fill color
`rimColor`	SWColor	Owned copy of the rim stroke + hub border color
`spokeColor`	SWColor	Owned copy of the spoke color template
`rotationAngle`	number	Current accumulated rotation in degrees; set by `rotate()`
`currentRadius`	number	Live rim radius. Equals `outerRadius` when `breathe()` is not active.
`hub`	SWDisk	Hub component (read-only intent)
`rim`	SWDisk	Rim component (read-only intent)
`spokes`	SWLine[]	Spoke array (read-only intent)

Methods

Drawing

Signature	Returns	Notes
`draw()`	void	Draws in raw screen/pixel coordinates. Use only when not working with a grid.
`drawOnGrid(grid)`	void	Preferred. Draws in user/grid coordinates via the given `SWGrid`. Draw order: rim → spokes → hub.

Animation

Signature	Parameters	Notes
`rotate(degPerSec, t)`	`degPerSec`: number `t`: number (s)	Sets `rotationAngle = degPerSec × t` and repositions all spokes. Positive = CCW in user space (CW on screen, due to Y-axis inversion). Call every frame.
`breathe(sinusoid, t)`	`sinusoid`: SWSinusoid `t`: number (s)	Sets `currentRadius` from `sinusoid.getValue(t)`, updates the rim disk, and repositions spokes. Call every frame.
`reset()`	—	Restores `rotationAngle` to 0 and `currentRadius` to `originalOuterRadius`. Call when the user resets the sketch.

Setters

Every setter keeps the internal SWDisk and SWLine components in sync automatically. All color setters apply copy-on-intake.

Method	Parameter	Notes
`setNumSpokes(n)`	`n: number`	Clamped to ≥ 1. Rebuilds the entire `spokes` array.
`setOuterRadius(r)`	`r: number`	Updates `outerRadius`, `originalOuterRadius`, `currentRadius`, rim disk radius, and spoke positions.
`setHubRadius(r)`	`r: number`	Updates the hub `SWDisk` radius.
`setSpokeThickness(w)`	`w: number` (px)	Calls `spoke.setThickness(w)` on every `SWLine` in the array.
`setRimThickness(w)`	`w: number` (px)	Pass 0 to hide the rim entirely (guarded in `draw`/`drawOnGrid`).
`setSpokeColor(swColor)`	`swColor: SWColor`	Each spoke receives its own copy. Pass `undefined` to clear color.
`setRimColor(swColor)`	`swColor: SWColor`	Sets rim stroke and hub border color together (shared visual role).
`setHubFillColor(swColor)`	`swColor: SWColor`	Sets the hub disk fill color.

Utility

Method	Returns	Example
`toString()`	string	`SWWheel(center:(0,0), outerRadius:120, hubRadius:10, numSpokes:10)`

Private Methods (internal — do not call directly)

Method	When called
`_buildComponents()`	Constructor only. Creates hub, rim, and initial spokes.
`_buildSpokes()`	Constructor and `setNumSpokes()`. Rebuilds the full `spokes` array.
`_repositionSpokes()`	Every call to `rotate()`, `breathe()`, `reset()`, and radius/count setters. Updates `ptA`/`ptB` of each existing spoke — faster than a full rebuild.

Usage Examples

Minimal wheel at the grid origin

// All defaults — 8 spokes, outerRadius 80, no colors set
let wheel, grid;

function setup() {
    createCanvas(400, 400);
    colorMode(HSB, 360, 100, 100, 100);
    grid  = new SWGrid( /* your grid params */ );
    wheel = new SWWheel();
}

function draw() {
    background(0, 0, 90);
    wheel.drawOnGrid(grid);
}

Custom wheel with color and rotation

let wheel, grid, tElapsed = 0;

function setup() {
    createCanvas(500, 500);
    colorMode(HSB, 360, 100, 100, 100);
    grid = new SWGrid( /* your grid params */ );

    wheel = new SWWheel({
        outerRadius:    120,
        numSpokes:      10,
        rimThickness:   8,
        spokeThickness: 8,
        rimColor:     new SWColor(210, 80, 100),  // blue
        spokeColor:   new SWColor(210, 80, 100),
        hubFillColor: new SWColor( 45, 90,  92),   // gold
    });
}

function draw() {
    tElapsed += min(deltaTime / 1000, 0.1);  // seconds, capped at 100 ms
    background(0, 0, 90);
    wheel.rotate(45, tElapsed);              // 45 °/sec CCW (user space)
    wheel.drawOnGrid(grid);
}

Breathing wheel (oscillating radius)

let wave, tElapsed = 0;

function setup() {
    // ...
    wave = new SWSinusoid({
        midValue:  100,   // center radius in user units
        amplitude: 30,    // ± 30 units
        period:    3,     // 3-second cycle
    });
}

function draw() {
    tElapsed += min(deltaTime / 1000, 0.1);
    wheel.rotate(60, tElapsed);
    wheel.breathe(wave, tElapsed);    // rim and spoke tips pulse together
    wheel.drawOnGrid(grid);
}

Invisible rim — the plus-sign configuration

// rimThickness:0 hides the rim; hubRadius:0 hides the hub.
// Result is a clean ✚ shape — the basis for SWCross (Stage 2).
const plus = new SWWheel({
    numSpokes:      4,
    rimThickness:   0,
    hubRadius:      0,
    spokeThickness: 2,
    spokeColor: new SWColor(270, 40, 75),
});

Wiring UI sliders to setters

// Call once in setup() after the wheel is created.
function wireWheelControls() {

    document.getElementById('numSpokesSlider')
        .addEventListener('input', e => wheel.setNumSpokes(+e.target.value));

    document.getElementById('rimThickSlider')
        .addEventListener('input', e => wheel.setRimThickness(+e.target.value));

    document.getElementById('rimColorPicker')
        .addEventListener('input', e => {
            wheel.setRimColor(hexToSWColor(e.target.value));  // your hex helper
        });
}

Source — `shapeClasses/swWheel.js`
