SWEyeball Saga

Class Reference — SWEyeball, SWPoint, SWColor & SWDisk

What Is `SWEyeball`?

SWEyeball is a self-contained class that draws a complete, animated eyeball using the p5.js canvas library. It encapsulates four separate disk objects and all of the geometry needed to make the pupil move, track a target, and stay constrained inside the white of the eye — so the sketch that uses the class only needs a few lines of setup code.

Rather than building the eye directly in a sketch (managing eight separate disk and point variables, writing custom drag math, and recomputing glint positions every frame), you create one SWEyeball and call a handful of friendly methods. The class is the result of ten stages of motivated development recorded in the SWEyeball Saga.

How the Layers Fit Together

Each eyeball is composed of four layers drawn back-to-front every frame:

┌─────────────────────────────────────────────────────────┐ │ SWEyeball │ │ │ │ Layer 1 (bottom) eyeBase SWDisk ← sclera │ │ Layer 2 pupil SWDisk ← iris + pupil │ │ Layer 3 topGlint SWDisk ← main glint │ │ Layer 4 (top) bottomGlint SWDisk ← fill glint │ │ │ │ Each SWDisk owns a center SWPoint (position anchor) │ │ Each SWDisk uses SWColor for fill and stroke colors │ └─────────────────────────────────────────────────────────┘ Dependency chain: SWEyeball → SWDisk → SWPoint (position) → SWColor (fill color) → SWColor (stroke color) → SWGrid (coordinate conversion)

Quick-Start: Two Eyes in a Sketch

The minimum code to get two draggable, mouse-following eyes onto a p5.js canvas:

// In setup() — after colorMode() and initializeSWColors():
let leftEye = new SWEyeball(
    new SWPoint(-2.5, 6),    // center position (grid user-units)
    2,                        // sclera radius
    2,                        // sclera border thickness
    [swWhite, swBlack],       // [sclera fill, sclera border]
    0.4,                      // pupil factor (40% of sclera radius)
    8,                        // iris ring thickness
    [swBlack, swBlue]         // [pupil fill, iris ring color]
);

let rightEye = new SWEyeball(
    new SWPoint(2.5, 6), 2, 2, [swWhite, swBlack], 0.4, 8, [swBlack, swBlue]
);

// In draw() — that's it for drawing:
leftEye.drawOnGrid(grid);
rightEye.drawOnGrid(grid);

// In mousePressed():
if (leftEye.handleMousePressed(mouseX, mouseY, grid))  return;
if (rightEye.handleMousePressed(mouseX, mouseY, grid)) return;

// In mouseDragged():
leftEye.handleMouseDragged(mouseX, mouseY, grid);
rightEye.handleMouseDragged(mouseX, mouseY, grid);

// In mouseReleased():
leftEye.handleMouseReleased();
rightEye.handleMouseReleased();

The Polar Coordinate System

The pupil position is stored internally as a polar offset from the eye center — a distance (radius) and a direction (angleDeg). All methods that move the pupil use this system:

Newcomer tip: Think of the angle like the hours on a clock face — except 0° is 3 o'clock (right), 90° is 12 o'clock (up), 180° is 9 o'clock (left), and 270° is 6 o'clock (down). The angular direction is counter-clockwise, which is the standard math convention.

Constructor Signature

new SWEyeball(
    eyeCenter,      // SWPoint  — position of the eyeball center in grid user-units
    radius,         // number   — sclera (white) radius in user-units
    baseThickness,  // number   — stroke weight for the sclera border
    eyeColors,      // SWColor[2] — [scleraFillColor, scleraBorderColor]
    pupilFactor,    // number   — pupil radius = radius × pupilFactor  (e.g. 0.4)
    irisThickness,  // number   — stroke weight for the iris ring around the pupil
    pupilColors     // SWColor[2] — [pupilFillColor, irisStrokeColor]
)

Important: Construct inside p5.js setup() — after calling colorMode() and initializeSWColors(). The glint geometry uses p5.js cos() and radians(), which are only available after p5 is running.

Public Properties You Can Read

Property	Type	Description
`eyeCenter`	SWPoint	Center of the entire eyeball. Changing this moves the whole eye.
`radius`	number	Sclera radius in user-units.
`pupilFactor`	number	Fraction of radius used for the pupil disk (e.g. `0.4` → 40%).
`pupilOffsetRadius`	number	Current distance of pupil center from `eyeCenter`. Updated live by drag and `setPupilOffset()`.
`pupilOffsetAngleDeg`	number	Current gaze direction in degrees [0, 360). Updated live.
`scleraColor`	SWColor	Fill color of the white sclera.
`borderColor`	SWColor	Stroke color of the sclera border.
`pupilColor`	SWColor	Fill color of the dark pupil center.
`irisColor`	SWColor	Stroke (ring) color around the pupil — the colored iris. Change live with `setIrisColor()`.
`isPupilDraggable`	boolean	Whether the pupil can be dragged. Default: `true`. Set before `rebuild()`.

Glint Customization Properties

Glints are the small white highlights that make the eye look shiny and alive. Override these before calling rebuild() to change their appearance:

Property	Default	Description
`glintFactor`	`0.4`	Top glint radius = pupilRadius × glintFactor.
`glintColor`	`swWhite`	Color applied to both glint disks.
`glintAngleDeg`	`135°`	Direction of the primary (top-left) glint from the pupil center. 135° = upper-left.
`glintBottomAngleDeg`	`315°`	Direction of the secondary (bottom-right) glint. 315° = lower-right.
`glintDistanceFactor`	`1.0`	Top glint distance = pupilRadius × factor.
`glintBottomDistFactor`	`0.7`	Bottom glint distance = pupilRadius × factor.

Private / Internal References

These are set by _buildComponents() and are available for reading (but should not be overwritten directly):

Property	Type	Description
`eyeBase`	SWDisk	The white sclera disk.
`pupil`	SWDisk	The iris/pupil disk. Its `.center` (SWPoint) is what moves.
`topGlint`	SWDisk	Primary top-left highlight disk.
`bottomGlint`	SWDisk	Secondary bottom-right highlight disk.
`_maxPupilOffset`	number	Maximum pupil travel distance = `radius − pupilRadius`. Read-only.
`_pupilRadius`	number	Cached pupil disk radius in user-units.

Drawing

drawOnGrid(grid) — Call every frame from draw().

Renders all four internal disks in the correct z-order (sclera → pupil → glints). The grid parameter is the SWGrid instance that handles the user-unit → pixel coordinate conversion.

// In p5.js draw():
leftEye.drawOnGrid(grid);
rightEye.drawOnGrid(grid);

draw() — Bypasses the grid and draws in raw screen pixels. Rarely needed; prefer drawOnGrid().

Programmatic Pupil Positioning

setPupilOffset(offsetRadius, angleDeg)

Moves the pupil to a polar position relative to the eye center. offsetRadius is automatically clamped to [0, _maxPupilOffset] so you can safely pass large values and the pupil stops at the boundary. angleDeg is normalized to [0, 360).

leftEye.setPupilOffset(0.8, 45);    // look up-right, 80% of max travel
rightEye.setPupilOffset(0, 0);      // center the pupil
leftEye.setPupilOffset(999, 270);   // look straight down — auto-clamped to max

// Read it back:
const { radius, angleDeg } = leftEye.pupilOffset;
console.log(`Pupil at r=${radius.toFixed(2)}, θ=${angleDeg.toFixed(0)}°`);

lookAt(targetUserX, targetUserY)

Points the pupil directly toward a target position (grid user-units), always using maximum offset so the gaze direction is fully visible. This is designed for high-frequency use inside draw() — it performs no console logging and is as fast as possible.

// In draw() — convert mouse to user-units first:
const { x: mouseUserX, y: mouseUserY } = grid.screenToUser(mouseX, mouseY);
leftEye.lookAt(mouseUserX, mouseUserY);
rightEye.lookAt(mouseUserX, mouseUserY);

Emergent vergence: When two eyes at different positions both call lookAt() with the same target, each computes the angle from its own center — so each eye points at a slightly different angle. This produces a natural "turning inward" (vergence) effect that was never explicitly programmed. It just falls out of the geometry.

lookAtAngle(angleDeg)

Companion to lookAt() for Track-ON mode, when a single shared angle has already been computed externally and both eyes should point in exactly the same direction.

// Track-ON mode: compute one shared angle from the midpoint between the eyes
const mid = { x: (leftEye.eyeCenter.x + rightEye.eyeCenter.x) / 2,
              y: (leftEye.eyeCenter.y + rightEye.eyeCenter.y) / 2 };
const dx = mouseUserX - mid.x;
const dy = mouseUserY - mid.y;
const sharedAngle = (degrees(Math.atan2(dy, dx)) + 360) % 360;

leftEye.lookAtAngle(sharedAngle);
rightEye.lookAtAngle(sharedAngle);

Mouse Interaction

handleMousePressed(mx, my, grid, tolerance=10) → boolean

Call from p5.js mousePressed(). Returns true if the user clicked on this eye's pupil (within tolerance screen pixels). That true signals that the click was "consumed" — other click handlers (like grid-toggle) should be skipped.

handleMouseDragged(mx, my, grid) → boolean

Call from p5.js mouseDragged() every frame while the button is held. Internally it converts screen → user coordinates, clamps the pupil inside the sclera boundary, moves the pupil and both glints, and syncs pupilOffsetRadius / pupilOffsetAngleDeg. Returns true while this eye is the one being dragged.

The constraint math inside handleMouseDragged():

// Step 1 — vector from eye center to raw mouse position
const dx = rawX - eyeCenter.x;
const dy = rawY - eyeCenter.y;

// Step 2 — how far does the user want to drag?
const dist = Math.sqrt(dx*dx + dy*dy);

// Step 3 — clamp if beyond the allowed maximum
if (dist > _maxPupilOffset) {
    const scale = _maxPupilOffset / dist;   // shrink to the legal length
    userX = eyeCenter.x + dx * scale;       // same direction, shorter magnitude
    userY = eyeCenter.y + dy * scale;
} else {
    userX = rawX;
    userY = rawY;                            // inside — no correction needed
}

handleMouseReleased()

Call from p5.js mouseReleased(). Clears the drag state.

Getters (Read-Only Properties)

isDragging → boolean

True while the user is actively dragging this eye's pupil. Use to prevent other code (like mouse follow) from overriding an in-progress drag.

if (!leftEye.isDragging) {
    leftEye.lookAt(mouseUserX, mouseUserY);
}

pupilOffset → { radius, angleDeg }

Returns the current polar position as a convenience object. Stays in sync with both setPupilOffset() and interactive drag.

Live Color Change

setIrisColor(swColor)

Changes the iris ring color immediately, without requiring a rebuild(). Also updates the stored irisColor so any future rebuild picks up the new value.

// Typical use — wired to a color picker 'input' event:
const newColor = SWColor.fromHex(colorPicker.value, 'irisColor');
leftEye.setIrisColor(newColor);
rightEye.setIrisColor(newColor);

setBaseAlpha(alpha)

Sets the sclera fill transparency (0 = invisible, 100 = fully opaque). Handy during development to see what's underneath.

Rebuilding After Glint Changes

rebuild()

Re-runs _buildComponents() after you change glint properties like glintFactor, glintAngleDeg, or glintColor. The existing pupil offset is preserved through the rebuild.

leftEye.glintFactor        = 0.6;  // larger glints
leftEye.glintAngleDeg      = 120;  // shift the highlight angle
leftEye.glintColor         = swGold;
leftEye.rebuild();                // reconstruct internal disks

Utility

toString() → string

console.log(leftEye.toString());
// → "SWEyeball(center: SWPoint(x:-2.5, y:6), radius: 2,
//             pupilFactor: 0.4, pupilOffset: r=1.200 θ=45.0°, dragging: false)"

SWEyeball is built on three smaller, reusable classes. Each one handles exactly one responsibility — a design principle called separation of concerns.

`SWPoint` — A Position in Space

SWPoint stores an (x, y) coordinate in grid user-units along with optional styling (stroke weight, color, label). It is the fundamental anchor for everything else: every disk, line, and triangle in the SketchWave system is positioned by giving it an SWPoint as its center or endpoint.

Key features:

setPosition(x, y) — move the point to new coordinates.
containsPoint(mx, my, grid, tolerance) — hit-test: is the mouse within tolerance pixels of this point on screen? Used for drag detection.
setDraggable(bool) — marks the point as interactive.
SWPoint.copy(other) — static deep-copy constructor. Creates an independent duplicate, including the pen trail and label offset.
Pen trail — optional: call point.penOn = true to record a history of positions, then draw the trail for motion effects.
drawOnGrid(grid) — draws the point as a visible dot on the grid. Useful during debugging.

// Create a point at (x=3, y=6) with a blue color label "B"
const pt = new SWPoint(3, 6, undefined, 8, swBlue, "B");
pt.showLabel = true;
pt.drawOnGrid(grid);

// Move it:
pt.setPosition(4, 5);

// Deep copy — the copy moves independently of the original:
const ptCopy = SWPoint.copy(pt);

Why use SWPoint instead of just (x, y)?
A plain pair of numbers can't be labeled, colored, hit-tested, or subscribed to by other objects. SWPoint is a named, styled, interactive object — which is why SWDisk takes one as its center rather than raw coordinates.

`SWColor` — A Color in HSB Space

SWColor stores a color as four numbers: hue (0–360), saturation (0–100), brightness (0–100), and alpha transparency (0–100). It works with p5.js's colorMode(HSB, 360, 100, 100, 100).

Key features:

new SWColor(h, s, b, a, name) — constructor. Hue is automatically wrapped to [0, 360).
SWColor.copy(other) — static deep copy. All SW classes store copies, so an external change to a color doesn't silently ripple through.
SWColor.fromHex(hexStr, name) — static factory that converts a CSS hex string (like "#3a7fd5") to HSB. Used to bridge HTML color pickers to the SketchWave system.
darken(factor), brighten(factor), saturate(factor), desaturate(factor), withAlpha(a) — return a new adjusted color without modifying the original.
initializeSWColors() — call once in setup() to initialize all global presets: swRed, swBlue, swGreen, swWhite, swBlack, and 30+ others.

// Predefined colors — initialized in setup() via initializeSWColors():
swBlack  = new SWColor(  0,   0,   0, 100, "black");
swWhite  = new SWColor(  0,   0, 100, 100, "white");
swBlue   = new SWColor(240, 100, 100, 100, "blue");
swRed    = new SWColor(  0, 100, 100, 100, "red");
swGold   = new SWColor( 45,  94,  92, 100, "gold");
// ...30+ more

// Adjust without modifying original:
const paleBlue = swBlue.withAlpha(40);

// Convert from hex (e.g. from HTML color picker):
const irisColor = SWColor.fromHex("#5c90c8", "iris");

Why HSB instead of RGB?
HSB maps directly to how artists think: hue = "which color?", saturation = "how vivid?", brightness = "how dark?". Darkening a color means subtracting from brightness — one number, predictable result. In RGB you'd have to adjust all three channels and guess.

`SWDisk` — A Styled Circle

SWDisk draws a filled, stroked disk (circle) at an SWPoint center position, in either screen pixel coordinates or grid user-units. It is the fundamental drawn primitive inside SWEyeball.

Key features:

new SWDisk(center, radius, thickness, fillColor, strokeColor) — all colors are copied on construction (no shared-reference surprises).
drawOnGrid(grid) — call every frame. Converts center from user-units to pixels, then draws the disk.
shouldShowCenter — boolean; show the center SWPoint as a visible dot (useful for debugging). Default: true. Set to false when used inside SWEyeball.
setFillAlpha(alpha), setStrokeAlpha(alpha) — change transparency after construction without a full rebuild.
breathe(sinusoid, t) — modulate radius with an SWSinusoid wave over time for animated pulse effects.
area, circumference — computed at construction.

// Standalone use:
const sclera = new SWDisk(
    new SWPoint(0, 0),   // center at origin
    2,                   // radius = 2 user-units
    2,                   // border thickness
    swWhite,             // fill color
    swBlack              // border color
);
sclera.shouldShowCenter = false;

// In draw():
sclera.drawOnGrid(grid);

// Transparent fill (reveal what's underneath for debugging):
sclera.setFillAlpha(30);

Inside SWEyeball: Each of the four layers (sclera, pupil, top glint, bottom glint) is an SWDisk. When you call leftEye.drawOnGrid(grid), it simply calls drawOnGrid(grid) on each of its four disks in order.

Files are loaded directly from the project folder. Use the Copy button to copy any file's full text to the clipboard.

Loading swEyeball.js…

Loading swPoint.js…

Loading swColor.js…

Loading swDisk.js…

SWEyeball Saga

What Is SWEyeball?

How the Layers Fit Together

Quick-Start: Two Eyes in a Sketch

The Polar Coordinate System

Constructor Signature

Public Properties You Can Read

Glint Customization Properties

Private / Internal References

Drawing

Programmatic Pupil Positioning

Mouse Interaction

Getters (Read-Only Properties)

Live Color Change

Rebuilding After Glint Changes

Utility

SWPoint — A Position in Space

SWColor — A Color in HSB Space

SWDisk — A Styled Circle

What Is `SWEyeball`?

`SWPoint` — A Position in Space

`SWColor` — A Color in HSB Space

`SWDisk` — A Styled Circle
