Overview

SWCross is a four-armed plus-sign (crosshair) shape that extends SWWheel. It hard-wires three design constraints — always 4 spokes, no visible rim, no visible hub — and adds an initialRotation property that pre-tilts the arms before animation begins.

All of SWWheel’s animation and drawing machinery (drawOnGrid(), breathe(), all setters) is inherited unchanged. SWCross only overrides rotate() and reset() to bake in the initial-rotation offset.

SWCross extends SWWheel │ ├── Locked: numSpokes = 4, rimThickness = 0, hub invisible ├── New: initialRotation (degrees) ├── New: setInitialRotation(deg) ├── Override: rotate(degPerSec, t) → adds initialRotation offset └── Override: reset() → returns to initialRotation, not 0 Inherited from SWWheel (unchanged): drawOnGrid(grid), breathe(sinusoid, t), setSpokeThickness(), setSpokeColor(), setSpokeCapStyle(), …

Default arm caps: SWCross defaults to SQUARE (flat-tip) cap style, overriding p5.js’s global default of ROUND. Flat tips make the crosshair geometry precise and clean. See the Cap Styles section for a full explanation.

Inheritance

SWCross uses single inheritance via the extends keyword. The constructor calls super() with three locked values, then adds its own initialRotation state.

Category	Item	How SWCross handles it
Inherited (unchanged)	`drawOnGrid(grid)`, `breathe(sinusoid, t)`	Used exactly as defined in `SWWheel`
Inherited (unchanged)	All setters: `setSpokeThickness()`, `setSpokeColor()`, `setSpokeCapStyle()`, etc.	Available on every `SWCross` instance
Overridden	`rotate(degPerSec, t)`	Sets `rotationAngle = initialRotation + degPerSec × t` instead of just `degPerSec × t`
Overridden	`reset()`	Returns arms to `initialRotation` (not 0°) and restores `originalOuterRadius`
New	`setInitialRotation(deg)`	Live setter that immediately repositions arms to the new base angle
Locked (not exposed)	`numSpokes`, `rimThickness`, hub colors	Hard-wired in `super()`; not constructor options

Dependencies

All six must be loaded in your HTML before SWCross.js:

Class / Library	File	Role
`p5.js`	CDN	Canvas and rendering engine
`SWColor`	`shapeClasses/swColor.js`	HSB color objects for arm stroke color
`SWPoint`	`shapeClasses/swPoint.js`	Center point and computed arm endpoints
`SWLine`	`shapeClasses/swLine.js`	Each individual arm (spoke)
`SWDisk`	`shapeClasses/swDisk.js`	Hub and rim components (invisible in SWCross)
`SWGrid`	`shapeClasses/swGrid.js`	Required only for `drawOnGrid()`
`SWWheel`	`shapeClasses/swWheel.js`	Parent class — must load immediately before `SWCross.js`

Constructor

const ps = new SWCross({ /* options — all optional */ });

All options are passed as a single destructured object. numSpokes, rimThickness, and hub colors are not accepted as options — they are locked:

Option	Type	Default	Description
`center`	SWPoint	SWPoint(0, 0)	Shape center in user/grid coordinates
`outerRadius`	number	100	Arm length in user units
`hubRadius`	number	6	Hub size in user units (hub is invisible; value kept for internal mechanics)
`spokeThickness`	number	25	Arm stroke weight in pixels
`spokeColor`	SWColor	undefined	Arm stroke color (SWColor instance)
`initialRotation`	number	0	Pre-tilt angle in degrees. 0° = plus ✚, 45° = times ✕

Locked value	Forced to	Why
`numSpokes`	4	Defines the plus-sign shape; other counts produce different shapes
`rimThickness`	0	Arms only — no enclosing ring
`hubFillColor`	null	Hub fill invisible
`rimColor`	null	Hub outline invisible
arm cap style	'SQUARE'	Flat tips; set via `setSpokeCapStyle()` after `super()`

Public Properties

All properties listed for SWWheel are present. The following are specific to SWCross:

Property	Type	Notes
`initialRotation`	number	Pre-tilt offset in degrees. Arms rest here at `t = 0`. Set via `setInitialRotation()`.

Inherited properties of note: rotationAngle stores the current computed angle (initialRotation + degPerSec × t). originalOuterRadius is what reset() restores currentRadius to.

Methods

Overridden Methods

Signature	Parameters	Behavior change from SWWheel
`rotate(degPerSec, t)`	`degPerSec`: number `t`: number (s)	Sets `rotationAngle = initialRotation + degPerSec × t`. At `t = 0`, arms rest at `initialRotation`, not 0°.
`reset()`	—	Restores `rotationAngle` to `initialRotation` (not 0) and `currentRadius` to `originalOuterRadius`.

New Setters

Method	Parameter	Notes
`setInitialRotation(deg)`	`deg: number`	Sets `this.initialRotation = deg`, `this.rotationAngle = deg`, and immediately repositions the arms via `_repositionSpokes()`. Always zero `tElapsed` after calling this so the animation clock restarts from the new pre-tilt baseline.

Key Inherited Methods (from SWWheel)

The full list is in the SWWheel Reference → Methods. The most commonly used ones are summarized here.

Method	Notes
`drawOnGrid(grid)`	Draw in user coordinates. Preferred over `draw()`.
`breathe(sinusoid, t)`	Oscillate arm length using an `SWSinusoid`. Call every frame.
`setSpokeThickness(w)`	Arm stroke weight in pixels.
`setSpokeColor(swColor)`	Arm color (each arm gets a defensive copy).
`setSpokeCapStyle(cap)`	Set cap style: `'ROUND'`, `'SQUARE'`, or `'PROJECT'`. Propagates to all four arms. See Cap Styles for details.
`setOuterRadius(r)`	Arm length in user units. Also updates `originalOuterRadius`.

Line Cap Styles — A p5.js Global State Lesson

⚠️ p5.js global state alert: strokeCap() is a global setting in p5.js. If any shape changes it during a frame, every subsequent shape drawn that frame inherits the new setting — unless something resets it. SWLine now brackets every line() call with explicit set & restore, so it never leaks its cap style to other shapes.

By default, p5.js draws all line endpoints with round caps. This is fine for general lines, but a geometric crosshair looks better with flat tips. The cap style is controlled per SWLine via this.capStyle ('ROUND' | 'SQUARE' | 'PROJECT').

The pattern used in SWLine.draw() and SWLine.drawOnGrid():

// Resolve string → p5 constant at draw time
strokeCap(window[this.capStyle] ?? ROUND);
line(x1, y1, x2, y2);
strokeCap(ROUND);  // restore p5's default so other shapes are unaffected

window[this.capStyle] looks up the p5 constant by name at draw time — so the string 'SQUARE' becomes the integer constant SQUARE without needing p5’s globals to be available when the class is first defined.

The Three Options

Value	p5 Constant	Visual Result	Default for
`'ROUND'`	`ROUND`	Semicircular end cap; line length equals exact nominal length	`SWLine` (p5 default)
`'SQUARE'`	`SQUARE`	Flat, blunt end; line length equals exact nominal length	`SWCross` — cleanest crosshair
`'PROJECT'`	`PROJECT`	Flat end that extends beyond the endpoint by ½ the stroke weight	None

Classroom tip: Set all three cap styles on the same plus sign using the Arm caps selector in swCross1.html to compare the visual difference. With a thick stroke weight (≥ 20 px), the difference between ROUND and SQUARE is very obvious. PROJECT visually lengthens the arms.

Usage Examples

Minimal plus sign at the grid origin

// All defaults — 4 arms, outerRadius 100, 25 px weight, no color set
let ps, grid;

function setup() {
    createCanvas(400, 400);
    colorMode(HSB, 360, 100, 100, 100);
    grid = new SWGrid( /* your grid params */ );
    ps   = new SWCross();
}

function draw() {
    background(0, 0, 90);
    ps.drawOnGrid(grid);
}

Diagonal cross (45° pre-tilt) with red arms

const cross = new SWCross({
    outerRadius     : 120,
    spokeThickness  : 20,
    spokeColor      : SWColor.fromHex('#ff0000', 100),
    initialRotation : 45   // ✕ orientation
});

Animated rotation with initialRotation offset

let ps, grid, tElapsed = 0;

function setup() {
    // ...
    ps = new SWCross({
        spokeColor      : new SWColor(0, 90, 90),
        initialRotation : 30    // starts 30° off the cardinal axes
    });
}

function draw() {
    tElapsed += min(deltaTime / 1000, 0.1);
    background(0, 0, 90);
    ps.rotate(60, tElapsed);     // 60 °/sec, offset by initialRotation
    ps.drawOnGrid(grid);
}

Changing initialRotation at runtime

// Wire a slider to setInitialRotation.
// IMPORTANT: reset tElapsed so animation restarts cleanly from the new angle.
document.getElementById('initialRotSlider')
    .addEventListener('input', e => {
        const deg = +e.target.value;
        ps.setInitialRotation(deg);
        tElapsed = 0;             // ← required to avoid jump
        redraw();
    });

Breathing plus sign

let wave = new SWSinusoid();
wave.adjustWaveUsingExtrema(40, 160);  // arms pulse from 40 to 160 user units
wave.setPeriod(3);

function draw() {
    tElapsed += min(deltaTime / 1000, 0.1);
    background(0, 0, 90);
    ps.rotate(45, tElapsed);
    ps.breathe(wave, tElapsed);   // inherited from SWWheel unchanged
    ps.drawOnGrid(grid);
}

Switching cap style at runtime

// Wire the Arm caps dropdown to setSpokeCapStyle().
document.getElementById('capStyleSelect')
    .addEventListener('change', e => {
        ps.setSpokeCapStyle(e.target.value);  // 'ROUND' | 'SQUARE' | 'PROJECT'
        redraw();
    });

Source — `shapeClasses/SWCross.js`

Loaded live from the file so this view always reflects the current version. Use the button to copy the full source to the clipboard.

Loading source…
